30 Minute Fire Light - NL604D
 |
30 Minutes Intergrity
Test
Standard:
BS 476: Part 20: 1987
General description of the assembly
- 6mm Pilkington PYROSHIELD safety clear glass
- Single glazing and double glazed with non-fire rated glass
- Horizontal mild steel framework
- Galvanised mild steel angles retaining framework
- Glass bedded using ceramic fibre tape
- Intumescent seals incorporated into the construction
Size Range:
Ventialtion:
Glazing Specification:
Insulation:
Foam or Cork insulation can be fitted externally
to suit your requirements.
Installation:
Supply on supply and fit is available
Cleaning / Maintenance:
Cleaning - Thermoformed roof lights should be washed
down with a mild detergent and warm water. Do not use abrasives.
Maintenance - Annually check mechanical components, and lubricate where necessary, acutate components
Main Frame Work:
Manufactured with 14 Gauge galvanised steel, powder
coated to suit your requirements. (maximm size unit, clear light size 1700mm
x 1700mm)
Test References: 62325 click here for report
Test Standards: B.S. 476 : Part 20 : 1987
Delivery period:
From reciept of all information (4 - 6 weeks)
